1966 Chrysler 300 Convertible

Muscle Car Era
CM27J63190948
440 CID V8 (350 HP) (350 HP)
Engine
Convertible
Body
Jefferson Plant, Detroit, MI
Plant
Muscle Car Era
Era
No factory image on file
1966 Chrysler 300

VIN Breakdown

PositionValueDecoded
Make Code C Chrysler
Class Code M Medium
Body Style Code 27 Convertible
Engine CID Code J 440 CID V8
Year Code 6 1966
Plant Code 3 Jefferson Plant, Detroit, MI
Serial Number 190948 Unit #190948

Basic Information

MakeChrysler
Model300
Year1966
Body StyleConvertible
ManufacturerChrysler Corporation
EraMuscle Car Era

Engine & Details

Engine440 CID V8 (350 HP) (350 HP)
Cylinders8
Displacement440 CID
Horsepower350 HP
Compression Ratio10.1:1
Carburetor4 BBL
Assembly PlantJefferson Plant, Detroit, MI
Plant Code3
Pattern SourceChrysler
Confidence95%

Original Specifications

Weight4015
Wheelbase124
Length221.9
Front tread62
Height55.5
Rear tread61..7
Width79.5

Source: Historical automotive documentation (1960-1972)

Powertrain Details Enhanced Data

Axle Type Semifloating

Pricing & Production Enhanced Data

Original Base Price $3936.00
No. Produced 2500

Body & Style Enhanced Data

No. Doors 2

Dimensions Enhanced Data

Weight 4015 lbs
Length 221.9 in.
Height 55.5 in.
Width 79.5 in.

Additional Specifications Enhanced Data

Type V8 overhead valve
Valve Lifters Hydraulic
Type Downdraft 4-barrel
Brake Horsepower 325@4800 hp
Colors Exterior Colors
Color Options (22)
Ignition System Distributor and coil
Cooling System Water pump
Radiator Tube and spacer
Battery 12 V
Exhaust System Single
Cooling System 17 Quarts
Fuel Type Premium
Optional Equipment Radio
Optional Equipment Power antenna
Optional Equipment Power brakes
Optional Equipment Power seats
Optional Equipment Power steering
Optional Equipment Power vent windows
Optional Equipment Power windows
Optional Equipment Air conditioning
Optional Equipment Torque Flite Eight automatic transmission
Optional Equipment Speed control device
Steering Gear Worm & ball nut
Rear Suspension Longitudinal leaf spring
Front Suspension Independent torsion bar
Drive Rear wheel drive
VIN Location On plate on left front door body hinge pillar post.
Spare Location Trunk
Tire Size 8.55 x 14
Make Chrysler
Origin United States
Model Year 1966
Series 300
Model Number BC2-M-27
Body Maker Chrysler
Service Hydraulic self-adjusting
Brake Size 11 in.
Emergency Rear service brakes
Fuel 25 gal.
Rear Differential 4 pt.
Oil 4 qt.
Transmission 6 pt.
Carburetor Carter
Compression Ratio-Std 10.0 :1
Lubrication Pressure to all bearings excluding wrist pin
Type Fully synchronized
Displacement 383 cu. in.
Rated Horsepower 57.8 hp
Cylinders 8
Torque 428@2800 ft/lbs
Main Bearings 5
Rear Tread 61..7 in.
Front Tread 62 in.
Wheelbase 124 in.
Differential Ratio 3.23 :1
Differential Hypoid
Clutch Type Single dry plate
No. Of Gears 3
1st 2.55 :1
2nd 1.49 :1
3rd 1 :1
5th Not applicable :1
Reverse 3.34 :1
B &s 4 1/4 & 3 3/8

Enhanced Data Note: The enhanced vehicle data shown above represents the base vehicle configuration as manufactured. Individual vehicles may vary depending on factory options and modifications made throughout the vehicle's history.
